Automotive Product Design Expert
Duration: 480 Hrs
(100% Placement Assistance)
CATIA v5
Content: Introduction To CATIA v5, Profile Creation, Part Design 3D, Dress-up Features, Reusing Data, Finalizing Design Intent, Sharing Information, Assembly Design, Drafting, Wireframe & Surface Design, Introduction to Surface Design, Creating Surfaces, Performing Operations on the Geometry, Completing the Geometry in Part Design, Sheet metal Products, Kinematics’ & Simulation on CATIA
Live Project
BIW Domain
Content:
- Introduction to BIW
- What are jigs & fixtures?
- 3-2-1 Principle
- Design of Clamp & Rest Mylar
- Design of Locating Pin & Diamond Pin
- Design of Riser
- Mylar, Locating Pin, Riser and L Bracket
- Dump Unit design
- Sheet metal Stamping and Formability
- Automotive Die design process
- Various Automotive Materials
- Various Joining Process
- Industrial Projects for practice
Plastic Domain
Content:
- Introduction to Plastics
- Material used in automotive plastics
- Thickness and fillets
- Defects in Plastics
- DFM, DFMA, TC, DFA, DFS
- Tooling direction
- Surface Quality analysis
- Environments
- A-B-C surface
- Interior Trims
- Exterior Trims
- Features adding
- Slider Lifter
- Master-section
There are no items in the curriculum yet.
