Plastic Design Domain Expert

BIW Plastic Domain  Expert

Duration: 300 Hrs

(100% Placement Assistance)

CATIA v5

Content: Introduction To CATIA v5, Profile Creation, Part Design 3D, Dress-up Features, Reusing Data, Finalizing Design Intent, Sharing Information, Assembly Design, Drafting, Wireframe & Surface Design, Introduction to Surface Design, Creating Surfaces, Performing Operations on the Geometry, Completing the Geometry in Part Design, Sheet metal Products, Kinematics’ & Simulation on CATIA

Live Project

Plastic Domain

Content:

• Introduction to Plastics
• Material used in automotive plastics
• Thickness and fillets
• Defects in Plastics
• DFM, DFMA, TC, DFA, DFS
• Tooling direction
• Surface Quality analysis
• Environments
• A-B-C surface
• Interior Trims
• Exterior Trims
• Features adding
• Slider Lifter
• Master-section
